Container Hospital Building

Due to the outbreak of large-scale epidemic, the hospital was overcrowded. In order to control the epidemic as soon as possible, Xiaotangshan Medical Hospital Container in Weihui was quickly completed and put into use with the help of Khome. The Medical Hospital Container adopts modular design and factory production. The container steel structure is the basic unit. It can be used alone or can be combined to form a spacious use space. The vertical direction can be stacked. The general specification of the container unit is 3000*5950*2800mm, including doors, windows, floor leather, and ceilings. The switches and power supply also have all been equipped before leaving the factory. In order to facilitate transportation, the ISO Container Hospital sent to Weihui is transported in separate parts, and then assembled at the construction site according to the drawings. Four workers can build a container unit in 2 hours. For this project, Khome completed the 676.85 square meters ISO Container Hospital within just 20 days. What a quick installatio!

Considered Factors in Container Hospital Design

The design of the container hospital is different from the permanent hospital building. The principle of container hospital design is to cut off the chain of infection and control the source of infection in three aspects: pathogen, host, and environment. In the plane layout, it is necessary to clarify the functional division and clarify the cleaning division, and the diversion of each department. On the plane layout, the medical area should be clearly divided into three areas: clean area, semi-clean area or semi-polluted area, and polluted area. Three streamlines should be clearly divided on the streamline: clean route, semi-polluted route, and polluted route. Special attention should be paid to the relative division of the patient activity area and the medical staff work area in the medical area, so as to reduce the chance of mutual infection between clean and polluted people and logistics.

The design of the Container Hospital Mobile should not only prevent the interference and pollution of the polluted environment outside the hospital area to the medical area in the hospital but also prevent the management and control of the pollution source in the hospital, so as not to cause secondary pollution. Disposable items, dirt ladders, gauze, food residues, patient excrement, blood samples, body fluid samples, and pathological tissue samples used by patients should be collected according to different infectious diseases, aseptic disinfection measures. All kinds of people flow should have clear scientific planning and strict measures should be taken. Therefore, the difficulties in container hospital design are

1. Confine the polluted area and in-situ disinfection;

2. Control the intermediate area and avoid contamination;

3. Protect the clean area from contamination.

At the same time, the design should take into account the medical environment for patients to see a doctor, as well as the environmental space of medical staff who work here for a long time, and try to create a humane, green, and ecological indoor and outdoor environment.

Feature of Container Hospital Building

1. Save transportation and storage space

After being packed, the container unit is only 1/4 of the volume of the original house, which is convenient for transportation

2. Factory pre-assembled to minimize on-site workload

All parts of the container are assembled in the factory. The columns and wall panels are bolted on-site, which can be quickly installed.

3. Rock wool as thermal insulation material, good fire performance

Rock wool sandwich panel has excellent thermal insulation and fireproof performance. This material not only has high strength and good thermal insulation performance but also has good fire resistance and flame retardant performance, reaching Class A. It is the preferred thermal insulation material for containers

4. Withstand earthquakes and strong wind

The structural parts of the containers are assembled with high-strength bolts to form a high-strength overall structure, which can resist earthquakes and strong wind.

5. Modular design, unlimited connection, and expansion

6. Standardized, easy to maintain and repair

7. Short delivery time.

Standard prefabricated production and stocking, manufacturing, and on-site preparation are carried out at the same time, and the installation is convenient.

8. Can be used multiple times, very environmentally friendly

FAQ?

Q1: Are you a factory or trading company?

A: We are a real factory; we have 3 plants in Xinxiang City, Henan Province, China.

Q2: Is third-party inspection available?

A: SGS, BV, TUV, etc. Are available, it is according to client requirements.

Q3: How about your delivery time?

A: Generally within 30 days, it is according to the order quantity, partial shipment is allowed for big orders.

Q4: What about the installation?

A: We'll provide the detailed installation drawing, supervisor guiding installation is available. We can do the turnkey jobs for some kind of project.
